HDT VICAT Testing Machine advanced testing solution for analyzing thermal deformation and softening temperature of polymer samples

Large Image : HDT VICAT Testing Machine advanced testing solution for analyzing thermal deformation and softening temperature of polymer samples

Product Details:

Place of Origin:	BEIJING, CHINA
Brand Name:	JINHAIHU
Certification:	ISO9001, CE
Model Number:	XRW-300F

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Packaging Details:	Standard export wooden cases
Delivery Time:	10~15 work days
Payment Terms:	T/T,L/C,D/A,D/P
Supply Ability:	15 sets per month

Contact Now

Detailed Product Description

Product Name:	HDT VICAT Testing Machine Advanced Testing Solution For Analyzing Thermal Deformation And Softening Temperature Of Polymer Samples	Current Source:	6KW, 220VAC, 50HZ
Test Stations:	6	Heating Medium:	Silicone Oils, Glycerine, Ethylene Glycol, Mineral Oil
Thermal Expansion Coefficient Of Specimen Holder:	<0.005mm/100℃	Equipment Size:	900mm×580mm×1400mm
Heating Rate B:	120℃/h	Span Of Sample Supports:	64mm, 100mm
Highlight:	HDT VICAT Testing Machine for polymer samples , HDT VICAT thermal deformation tester , VICAT softening temperature analyzer

HDT VICAT Testing Machine

Advanced testing solution for analyzing thermal deformation and softening temperature of polymer samples with exceptional precision and reliability.

Product Overview

The HDT Vicat Tester maintains ultra-stable thermal regulation throughout testing procedures with maximum temperature tolerance error of merely ±0.5℃, ensuring highly consistent and accurate thermal test conditions. Featuring automated lifting and lowering structure for simplified operations and minimized manual errors.

Compact structural design (900mm×580mm×1400mm) saves laboratory space while providing professional thermal performance detection for plastic materials.

Technical Specifications

Parameter	Specification
Product Name	HDT VICAT Testing Machine
Heating Rate A	50℃/h
Heating Rate B	120℃/h
Temperature Control Deviation	±0.5℃
Power Supply	6KW, 220VAC, 50HZ
Temperature Range	Ambient temperature to 300℃
Loading Specifications	10±0.2N and 50±1.0N
Deformation Measurement	-1.00mm to 10.00mm
Specimen Support Span	64mm and 100mm

Key Features

Professional temperature-dependent Vicat and heat deflection testing measurement system
Microprocessor-driven PID temperature regulator for precise control
High-accuracy displacement transducer for reliable measurements
Intuitive human-machine interface for straightforward operation
Multiple heat transfer medium options (silicone oil, glycerin, ethylene glycol, mineral oil)
Automated test frame operation reduces manual intervention

Applications

Plastic Manufacturing: Determines softening temperature of thermoplastic materials (PVC, PPR, ABS) for quality supervision and product development
Research & Development: Analyzes thermal performance characteristics of new plastic materials for optimized processing parameters
Third-Party Testing Laboratories: Provides highly repeatable detection data with simple operation for material verification and compliance testing

Support & Services

We provide comprehensive technical assistance and services for sustained stable operation of your HDT VICAT Testing Machine:

On-site installation and operational training
Periodic calibration and routine maintenance
Professional technical advisory and fault diagnosis support
Component repair and spare part replacement
Software iteration and function upgrading

Frequently Asked Questions

Could you introduce the XRW-300F VICAT Testing Machine?

The XRW-300F serves as testing apparatus designed to detect Vicat softening point and heat deflection temperature of thermoplastic materials in compliance with ISO9001 standards.

Where does the manufacturing of XRW-300F VICAT Testing Machine take place?

The XRW-300F VICAT Testing Machine is manufactured in Beijing, China.

Which qualification certification is available for the XRW-300F VICAT Testing Machine?

The XRW-300F VICAT Testing Machine meets the requirements of ISO9001 certification and CE marking.

What MOQ applies to the XRW-300F VICAT Testing Machine?

The minimum order quantity is one set.

What is the monthly supply capacity of the XRW-300F VICAT Testing Machine?

We can provide up to 15 sets of the equipment every month.

How long will it take to deliver the XRW-300F VICAT Testing Machine after placing an order?

The lead time ranges from 10 to 15 working days.

What packaging method is adopted for the XRW-300F VICAT Testing Machine during shipment?

The XRW-300F VICAT Testing Machine adopts standard export wooden case packaging.

Product Images
