Lightweight Plastic Pipe End Caps
Designed for easy handling and installation while providing reliable pipe end coverage during testing procedures.
Product Overview
Our Plastic Pipe End Caps feature extensive applicability, primarily designed for sealing test specimens of PVC, PE, PP-R, ABS, and composite pipes. Engineered for seamless compatibility with Plastic Pipe Hydrostatic Pressure Testing Machines, these end caps offer customizable connectors (M12*1.25 or 1/4'') to match specific application requirements.
Manufactured in strict compliance with international standards ISO1167 and ASTM D 1598/1599, our end caps maintain premium quality and withstand rigorous testing environments. They provide optimal and reliable end sealing for thermoplastics pressure piping during testing procedures, delivering accurate, consistent, and trustworthy test results.
Key Features
- High-temperature resistant silicone sealing rings prevent test media leakage
- Compatible with PVC, PE, PP-R, ABS, and composite pipe samples
- Suitable for hydrostatic, blasting, and negative pressure testing
- Precision casting technology ensures stable structure and strong pressure resistance
- Standard export wooden case packaging for transport protection
- Easy installation and disassembly with high sealing performance
- Customizable to meet specific customer requirements
Technical Specifications
| Product Category |
Plastic Pipe End Caps |
| Sealing Ring |
O-ring |
| Applicable Pipe Diameter |
φ63~φ63+0.6mm |
| Delivery Time |
3~5 days |
| Manufacturing Technics |
Precision Casting |
| Compliance Standards |
ISO1167, ASTM D 1598/1599 |
| Type |
A |
| Model |
DN 63mm |
| Material |
304# Stainless Steel |
| Maximum Pressure |
10 MPA |
Applications
JINHAIHU XGY Plastic Pipe End Caps are premium-grade testing accessories certified by ISO9001, manufactured in Beijing, China. Core applications include:
- End closure for long-term hydrostatic strength testing of pipes
- End cover for thermoplastic pressure piping systems
- End-shield cover for short-term pressure and leaktightness testing of pipe assemblies
The silvery white appearance facilitates quick identification during testing operations and ensures excellent compatibility with different working environments. Embedded high-temperature resistant silicone seal rings deliver robust sealing performance, effectively preventing test media leakage.
Pricing & Order Information
Price Range: 80-110 USD per set
Minimum Order Quantity: 1 set
Monthly Supply Capacity: 1000 sets
Delivery Time: 3-5 working days
Payment Options: T/T, L/C, Western Union, MoneyGram, D/P, D/A
Frequently Asked Questions
What is the brand name of the plastic pipe end caps?
Manufactured under the brand JINHAIHU.
What is the model number?
XGY model.
What quality certifications are available?
ISO9001 quality system certification.
What is the minimum order quantity?
1 set.
What is the delivery time?
3-5 working days.
