Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters

Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters
Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters
video play

Large Image :  Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters

Product Details:
Place of Origin: BEIJING, CHINA
Brand Name: JINHAIHU
Certification: ISO9001
Model Number: 1/2"
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Standard export wooden cases
Delivery Time: 5~10 work days
Payment Terms: T/T,L/C,Western Union,MoneyGram,D/P,D/A
Supply Ability: 200 sets per month
Contact Now
Detailed Product Description
Product Name: Durable Plastic Pipe End Caps Designed For Sealing And Pressure Testing Of Pipes Ranging From 16 To 1600 Millimeters Standards: ASTM D2466, EN921, ISO1167, ASTM D 1598/1599
Exterior Size(mm*mm): φ60*60mm Material: 304# Stainless Steel
Model: 1/2" Color: Silvery White
Product Category: Plastic Pipe End Caps Seal Ring: Type O, Silicone Rubber
Highlight:

Durable plastic pipe end caps

,

Pipe end caps for pressure testing

,

Plastic pipe caps 16-1600mm

Durable Plastic Pipe End Caps for Sealing and Pressure Testing
Product Overview

These pipe end caps feature user-friendly operation and stable, reliable sealing performance for pipes ranging from 16 to 1600 millimeters.

  • Available in carbon steel and stainless steel material versions
  • Custom fixtures for non-standard specifications available
  • Ideal for pipeline pressure testing applications
  • Complies with GB/T 15560 and GB/T 6111-2003 standards
Available Specifications

Imperial Inch Sizes: 1/2", 3/4", 1", 1 1/2", 1 3/4", 2", 2 1/2", 2 3/4", 3", 4", 5", 6", 8", 10", 12", 14", 16", 20", 22", 24", 28"

Metric Outer Diameter (Φ): Φ16, Φ20, Φ25, Φ32, Φ40, Φ50, Φ63, Φ75, Φ90, Φ110, Φ125, Φ140, Φ160, Φ200, Φ225, Φ250, Φ280, Φ315, Φ355, Φ400, Φ450, Φ500, Φ560, Φ630, Φ710, Φ800, Φ900, Φ1000, Φ1200, Φ1400, Φ1600

Custom sizes available upon request

Key Features
  • 1/2" A-type structure for internal hydrostatic testing
  • Specifically designed for sealing PE and PVC thermoplastic pipe samples
  • Tie-rod-free design with outstanding ultra-high pressure resistance
  • Precision casting technology for elegant, smooth appearance
  • One-step integration of sealing and clamping
  • 100% success rate of one-time reliable sealing
Technical Parameters (1/2" Model)
Parameter Value
Maximum Diameter (mm) φ60
Height of One End (mm) 60
Weight of One End (KG) 0.5
O-ring Size (mm) φ19×3
Maximum Pressure (MPa) 20
Nominal Value (MPa) 12
Compliance Standards

This product series conforms to authoritative international and Chinese national testing specifications:

  • ASTM D1598-2004
  • ASTM D1599
  • ASTM D2466
  • GB/T 6111-2018
  • GB/T 15560-1995
  • GB/T 18252-2008
  • GB/T 18476-2001
  • Other relevant industrial standards
Support & Services

Our professional technical support team provides comprehensive assistance with installation, troubleshooting, and best practices for optimal performance.

Value-added services include:

  • Custom sizing and specifications
  • Product labeling and marking
  • OEM manufacturing
  • Private labeling
  • Tailored solutions for specific requirements
Packaging & Shipping

Packaging: Supplied in sets of two, packed in reinforced wooden cases. Each end cap is individually wrapped to prevent damage during transit.

Shipping: Standard delivery within 5-15 business days. Expedited shipping available at additional cost.

Frequently Asked Questions
What brand is this product?
JINHAIHU
What is the model code?
XGY
Does this product have quality certification?
Yes, certified in accordance with ISO9001
What is the minimum order quantity?
1 set
What payment terms are available?
T/T, L/C, Western Union, MoneyGram, D/P, and D/A
Product Images
Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters 0 Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters 1 Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters 2 Durable Plastic Pipe End Caps Designed for Sealing and Pressure Testing of Pipes Ranging from 16 to 1600 Millimeters 3
