Durable Plastic Pipe End Caps with Silicone Seal Rings Embedded in Metal Rings
Plastic Pipe End Caps with Silicone Seal Rings embedded in metal rings serve as a high-efficiency solution for sealing and capping the ends of plastic pipes. Specifically engineered to achieve a precise fit on pipe ends, these Plastic Tube End Caps deliver reliable, leak-tight sealing performance.
Product Overview
Adopting a clamp-first-then-seal assembly process, they ensure a 100% success rate for one-time clamping and sealing. Manufactured in strict compliance with GB/T 6111, EN921, ISO 1167, and ASTM D 1598/1599 standards, these PVC Pipe End Covers guarantee superior quality and the ability to withstand harsh working conditions. The use of high-grade 304# stainless steel in the manufacturing process ensures these end caps boast an extended service life and consistent, superior operational performance.
Available Sizes
Imperial (inch) specifications:
- 1/2", 3/4", 1", 1 1/2", 1 3/4", 2", 2 1/2", 2 3/4", 3", 4", 5", 6", 8", 10", 12", 14", 16", 20", 22", 24", 28", and other customizable sizes
Metric nominal outer diameters (Φ):
- Φ16, Φ20, Φ25, Φ32, Φ40, Φ50, Φ63, Φ75, Φ90, Φ110, Φ125, Φ140, Φ160, Φ200, Φ225, Φ250, Φ280, Φ315, Φ355, Φ400, Φ450, Φ500, Φ560, Φ630, Φ710, Φ800, Φ900, Φ1000, Φ1200, Φ1400, Φ1600
Technical Parameters
| Model |
1 1/4" |
| Max. Diameter (mm) |
φ70 |
| Height of one end (mm) |
65 |
| Weight of one end (KG) |
0.7 |
| O-ring size (mm) |
φ40*3 |
| Max. pressure (Mpa) |
15 |
| Nominal value (Mpa) |
10 |
Quality Standards
ASTM D1598-2004, ASTMD1599, ASTM D 2466, GB/T6111-2018, GB/T15560-1995, GB/T18252-2008, GB/T18476-2001, etc.
Support and Services
Our dedicated technical support team stands ready to resolve all inquiries and issues concerning the installation and application of our Plastic Pipe End Caps. We offer comprehensive product specifications, targeted troubleshooting solutions, and expert guidance on standard operating procedures.
Value-Added Services:
- Customized dimension processing
- Personalized marking
- OEM production
- Private labeling
Packaging and Shipping
Product Packaging: Our Plastic Pipe End Caps are supplied in sets of 2, and each set is packed in heavy-duty export wooden crates to guarantee transit safety. Each individual end cap is wrapped with professional protective material.
Shipping Services: We provide standard shipping services with delivery lead times ranging from 5 to 15 business days. Expedited shipping services are available for urgent delivery needs.
Frequently Asked Questions
Q1: Which brand is this product manufactured under?
A1: This product is manufactured under the JINHAIHU brand.
Q2: What is the official model designation of this product?
A2: The official model designation of this product is XGY.
Q3: Does this product possess formal quality certification?
A3: Yes, this product is certified in accordance with the ISO9001 quality management system.
Q4: What is the minimum order quantity for this product?
A4: The minimum order quantity for this product is 1 set.
Q5: What payment terms are available for this product?
A5: We accept a full range of payment terms for this product, including T/T, L/C, Western Union, MoneyGram, D/P and D/A.
