| Product Name: | Thermal Deformation Temperature Tester Plastic-deternimition Of Temperature Of Deflection Under Load | Mainframe Type: | Table Type |
|---|---|---|---|
| Heating Rate: | 120℃/h 、 50℃/h | Maximum Temperature Error: | ±0.5℃ |
| Deformation Measurement Range: | -1.00～10.00mm | Span Of Sample Supports: | 64mm, 100mm |
| Maximum Deformation Measurement Error: | 0.01mm | Current Source: | 3000VA 220VAC 50HZ |
| High Light: | Plastic deternimition Thermal deformation temperature tester,3000VA Thermal Deformation Temperature Tester,220VAC Thermal Deformation Temperature Tester |
||
Overview:
KRW-300D series products are designed and manufactured according to the latest international standards and national standards. It is suitable for measuring the vitamin softening point temperature and thermal deformation temperature of polymer materials. The instrument adopts digital LCD display, dial meter measure displacement, stable and reliable quality, measurement data is accurate.
Product Introduction:
The ISO 75 ASTM D 648 Thermal Deformation Vicar softening point tester is designed to adapt to the rapid development of the plastics industry and improve the level of material research and testing. They adopt the latest international and national standards :ISO 75-1-1993 plastics; GB/ T1633-2000 Thermoplastic materials - Vica softening temperature (VST) determination and GB/ T1634-2001 plastics; Determination of flexural temperature under load. Controlled by computer, stable performance, easy operation, high degree of automation, is the most advanced non-metallic material deflection and Vica softening temperature test instrument.
Test Standards:
GB/T1633, GB/T1634, ISO75, ISO306,ASTM D648, ASTM D1525,ISO 2507
Technical Parameter:
| Temperature control range | Room temperature ～300℃ |
| Heating rate | 120℃/h , 50℃/h |
| Maximum temperature error | ±0.5℃ |
| Temperature measurement point | 1 |
| Test station | 2,3,4,6 Optional |
| Formal measurement measuring tool | Digital display dialgauge |
| Deformation measurement range | -1.00～10.00mm |
| Span of sample supports | 64mm,100mm |
| Maximum deformation measurement error | 0.01mm |
| Thermal expansion coefficient of specimen holder | <0.005mm/100℃ |
| heating medium | Methylsilicone oil |
| Cooling method | Natural cooling above 150℃, water cooling or natural cooling of 150℃ below |
| Upper limit temperature protection | Stop the heating automatically when the test temperature reaches the upper limit temperature. |
| Current source | 3000VA 220VAC 50HZ |
Support and Services:
HDT VICAT Testing Machine provides a wide range of technical support and services to ensure peak performance and maximum uptime. We offer on-site installation services, operator training, preventive maintenance, and troubleshooting assistance.
Installation and SetupOur experienced technicians will install and setup the HDT VICAT Testing Machine at your site and provide operator training.
Preventive MaintenanceWe offer scheduled preventive maintenance services to ensure the optimal performance of the HDT VICAT Testing Machine.
Troubleshooting AssistanceWe provide troubleshooting assistance to help you identify and resolve any issues with the HDT VICAT Testing Machine.
Packing and Shipping:
The HDT VICAT Testing Machine is packed in a wooden box to ensure that it is safe and secure during transport. The wooden box is lined with bubble wrap and foam to protect the machine from any external damage. The machine is then sealed with a plastic wrap to protect it from moisture. The box is then labeled with the exact contents of the package so that it can be easily identified. The machine is then shipped using a reliable carrier such as UPS or FedEx.
