    Product Details:

    Place of Origin: BEIJING, CHINA
    Brand Name: JINHAIHU
    Certification: ISO9001
    Model Number: XWW-

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD 5000~6500/ set
    Packaging Details: Standard export wooden cases
    Delivery Time: 10~20 work days
    Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Product Name: Microcomputer Control Single-Armed Electronic Universal Testing Machine Capacity: 5,10,20,50,100,200KG
    Alternative: Tensile Testing Machine Resolution: 1/300,000
    Test Speed Range: 0.05~500 Mm/min Motor: Panasonic Servo Motor
    Standard: ISO 7500-1 ISO 572 ISO 5893 ASTM D638/695/790, Etc

    Microcomputer Control Single-Armed Electronic Universal Testing Machine



    Description:

       Microcomputer Control Single-Armed Electronic Universal Testing Machine mainly applied to test the metallic and non-metallic materials in tension, compression, bending, shear, peel,tear or two-points extensions and others., such as rubber, plastic, wire and cable, optical fiber and cable, safe belt, leather belt composite materials, plastic profiles, waterproof membrane, steel, copper,profiles, spring steel, bearing steel,stainless steel (as well as other high-hardness steel), castings, plate,strip, non-ferrous metal wire .



    Maintechnical parameter of Microcomputer Control Single-Armed Electronic Universal Testing Machine:

    Model XWW-100N/200N/500N/1000N/2000N
    Type Door model
    Max. Load 100N/200N/500N/1000N/2000N
    Unit Switchover Tone,Kg,g,Kn,Lb; mm,cm,inch
    Accuracy Grade 0.5%
    Force-measuring Range 0.4%~100%FS
    Force-measuring Accuracy ≤0.5%
    Deformation-measuring Range 2%~100%FS
    Deformation-measuring Accuracy 1%
    Crossbeam Displacement Resolution 0.001mm
    Crossbeam Speed Range 0.01~500mm/min
    Displacement Speed Accuracy ≤ 0.5%
    Tensile Space 700mm
    Compression Space 900mm (or according to order)
    Clamps Wedge Grip,Compressing Attachment,Bend accessorises
    PC System Equiped with brand computer
    Power Supply AC220V
    Standards

    ISO 7500-1 ISO 572 ISO 5893 ASTMD638695790

    Weight 200KG



    Introduction of the UTM software:



    Universal Testing Machine Software (more than the following)

    • This software is of powerful function, including programs of tensile, compressing, bending, sheering, peeling tests on metallic, non-metallic, and other various materials.
    • Based on Windows, simple operation and easy to learn.
    • Languages switch between Simplified Chinese, traditional Chinese and English.
    • Ten user accounts and passwords can be created.
    • It has the protection function of overloading: overloading value can be set by user.
    • The units of force or displacement can be switched easily. The changes in stress and strain are displayed real time.
    • Curves, like Load-displacement, load-time, displacement-time, stress-strain, load-tensile length, etc. can be switched between each other at any time.
    • Force value dual-correction system: auto set and zero, auto identification and import of correction data.
    • It is suitable for many testing standards, such as ISO, JIS, ASTM, DIN, GB etc.
    • Compare among the test curves in the same group though piling them up.

    Auto zero set. Max force, upper-yield strength, lower-yield strength, anti-tensile intensity anti-compression strength, elasticity modulus, percentage of elongation, etc. are calculated automatically.
